Details
QZL -230  Micro Pellet System

General applications
This machine makes damp granule into beautiful pellet by setting rotating centrifugal disk, blower, and pneumatic nozzle. Feed damp granule into rotating centrifugal disk, start fan then start rotating centrifugal disk. It can make the damp granule undertaken the action of air loating force in ring gap, rotating centrifugal strength and gravity itself, appear circle rope-turning movement and become high-degree ball shape pellet.

Technical Data

Specification	230	400	550	700	1000	1300
Power (Kw)	0.75	2.2	3	3.7	5.5	7.5
Capacity (kg/h)	2.5-4	5-48	10-50	40-80	70-200	100-300
